Agilent Technologies Infinity II 1290

120 Agilent 1290 Infinity II Flexible Pump User Manual
7 Maintenance
Pump Head Procedures
Replace Wash Seal and Gasket
1 To remove the wash seal use the steel side of the insert
tool.
2 Use the soft plastic side of the insert tool for inserting the
wash seal into the support ring.
NOTE
Clean seals before Reinstallation or use new ones.
HINT
Store seals in isopropanol bath before installation.
Wash seal
>chZgiidda
LVh]hZVa
Hjeedgig^c\
Heg^c\
HZVa
