186 Agilent 1290 Infinity II Flexible Pump User Manual
10 Hardware Information
Setting the 8-bit Configuration Switch
Special Settings
The special settings are required for specific actions (normally in a service case).
Boot-Resident
Firmware update procedures may require this mode in case of firmware
loading errors (main firmware part).
If you use the following switch settings and power the instrument up
again, the instrument firmware stays in the resident mode. It is not
operable as a module. It only uses basic functions of the operating system
for example, for communication. In this mode the main firmware can be
loaded (using update utilities).
Forced Cold Start
A forced cold start can be used to bring the module into a defined mode
with default parameter settings.
If you use the following switch settings and power the instrument up
again, a forced cold start has been completed.
The tables include both settings for modules ā with on-board LAN and without on-board
LAN. They are identified as LAN and no LAN.
Tabl e 8 Boot Resident Settings (On-board LAN)
Mode Select SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
TEST/BOOT11100000
Loss of data
Forced cold start erases all methods and data stored in the non-volatile memory. Exceptions
are calibration settings, diagnosis and repair log books which will not be erased.
ā Save your methods and data before executing a forced cold start.
Tabl e 9 Forced Cold Start Settings (On-board LAN)
Mode Select SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
TEST/BOOT11000001
