Page 20 VK 7025 Dissolution Apparatus Revision H, 11/10
Setup Operator’s Manual P/N 70-9033
Varian, Inc.
Step 2. Remove all packing from the dissolution apparatus.
Step 3. There are four lifting straps included with the dissolution apparatus. One
is positioned around each of the four legs.
Step 4. Place the straps around your wrist as indicated in Figure 1, “Lifting
Straps,” below.
FIGURE 1. Lifting Straps
Step 5. Use the lifting straps to lift the dissolution apparatus off of the packing
platform. Place the dissolution apparatus on the ground.
Warning
The VK 7025 weighs approximately 200 pounds and therefore
requires special handling.
Warning
Because of its heavy weight, two people should lift the tester. Do
not lift the tester by the drive unit. Lift by holding the base plate.
