Revision H, 11/10 VK 7025 Dissolution Apparatus Page 111
P/N 70-9033 Operator’s Manual Maintenance and Troubleshooting
Varian, Inc.
Printer Configuration
Step 1. Turn off the dissolution apparatus.
Step 2. Press and hold the printer toggle switch in the OnLine / Off Line position
while turning on the instrument. Hold the printer toggle switch in the
OnLine / Off Line position for six seconds after the instrument is turned
on, then release the switch.
Step 3. The printer should print: ***
SETUP MENU *** and CONFIGURE... [NEXT/OK].
If this message does not print, repeat steps 1 through 3.
Step 4. The printer toggle switch is used to complete the configuration. Pressing
the left side of the printer toggle switch selects
NEXT to advance to the
next menu item. Pressing the right side of the printer toggle switch
selects
OK to accept what is stated on this line of the menu item. Each
time the switch is pressed, another part of the menu prints. Allow the
printer to finish printing before pressing the switch again. See the table of
commands on the following page.
Note
The printer configuration is set by the factory. This procedure
should be performed only if the printer displays erroneous
characters. Contact the Dissolution Systems Service
Department for assistance, if necessary.
Note
The printout is easier to read if the printer cover is removed.
