Chapter 6 Fiber Optics
Installing Fiber Optics
To install and set the height for the fiber optic assemblies, complete the following steps:
Step 1. Log into the VK 7025 as an administrator.
Step 2. Clip the ferrule onto the fiber optic probe (see Figure 15, “Fiber Optic
Assembly,” below).
FIGURE 15. Fiber Optic Assembly
fiber optic probe
ferrule
