Revision H, 11/10 VK 7025 Dissolution Apparatus Page 51
P/N 70-9033 Operator’s Manual Administrator Operation
Varian, Inc.
Step 2. From the Calibration Menu screen, select CANNULA HEIGHT
CALIBRATION. The Set Sampling Depth screen displays with
factory-set values for each apparatus.
Step 3. If you are using paddle over disk or rotating cylinder, select MENU 2 to
view these apparatus.
Step 4. To ensure the cannulas are in their home position, select MOVE DOWN
to move the cannulas to their lowest position, then select MOVE UP to
move the cannulas to their highest position.
Step 5. Select MOVE UP or MOVE DOWN to position the cannulas at the
appropriate height in the vessels.
SET SAMPLING DEPTH
BASKET 900 mL
200
MOVE
UP
BASKET 500 mL
400
MOVE
DOWN
PADDLE 900 mL
200
PADDLE 500 mL
400
MENU 2
CANNULA POSITION = 0
Note
The factory-set number displayed under each option is not a
distance measurement. It refers to the number of steps the
cannula motor moves.
To Next Page
