Page 74 VK 7025 Dissolution Apparatus Revision H, 11/10
Operation Operator’s Manual P/N 70-9033
Varian, Inc.
Print Method Use this option to print the method parameters.
To print the information stored under the method number displayed on
the Start Method screen, select PRINT METHOD. The printer must be
turned on and enabled.
To enable the Report Center Printer, see “Print Reports” on page 90.
Lot / Batch Data To enter information about the product being tested, select LOT / BATCH
DATA. The Lot / Batch Data Menu 1 screen displays. The following
options are listed: Product Name, Lot Number, Batch Number, Note, and
Menu 2 (which displays Ref. Number and Strength).
Select the parameter and the cursor flashes on the corresponding line.
Enter the appropriate information for each item up to 25 characters.
Additional notes and comments up to 30 characters can be entered by
selecting NOTE. Complete each field using any combination of letters or
numbers. To display a letter, hold down the number key until the
appropriate letter displays, then release the key. Press ESC to return to
the Start Method screen.
When running a method, the text displays on the printout along with the
method parameters. In manual operation, the lot / batch data note does
not display on the printout.
Instant Start Use this option to begin the test according to the currently selected
method. See “Instant Start” on page 75.
Delay Start
(VK 7025 with
Paddles)
This option displays only when using paddles with a VK 7025.
Use this option to program the test to begin automatically on a specific
date and time. See “Delay Start” on page 82.
Option Response
