Aiphone IX SERIES User Manual

10
Before Using
Part Names
2
Number Name & description
1 Handset (IX-MV7-HW and IX-MV7-HB only)
2 Touchscreen LCD
3 Camera
4 Status indicator (Orange/Blue)
Shows the status of this station.
(→page 11)
5 Microphone
6 Home button
Press this to display the Home Screen. Pressing this while the Home Screen is displayed will switch
the station into standby mode.
(→page 14)
7 Speaker
8 Reset button
To be used by personnel only. Do not press.
9 microSD card slot
Used for inserting or removing a microSD card (sold separately).
(→page 27)
10 microSD card slot cover
11 3.5 mm 4-pole stereo mini jack (CTIA standard)
Used to connect a 3rd party headset.
(→page 24)
12 Camera angle adjustment lever
Used to adjust the angle of the camera vertically.
(→page 13)
13 Camera privacy cover lever
Used to hide the camera.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
