IP Router Configuration
7705 SAR OS Router Configuration Guide 197
tunnel-table
Syntax tunnel-table [ip-address[/mask]] [protocol protocol | sdp sdp-id] [summary]
Context show>router
Description This command displays tunnel table information.
Note that auto-bind GRE tunnels are not displayed in the show command output. GRE tunnels are not
the same as SDP tunnels that use the GRE encapsulation type.
Parameters ip-address/mask — displays the specified tunnel table’s destination IP address and mask
protocol — displays LDP protocol information
sdp-id — displays information about the specified SDP
summary — displays summary tunnel table information
Output The following output is an example of tunnel table information, and Table 38 describes the fields.
Table 37: Show Router Status Output Fields
Label Description
Router The administrative and operational states for the router
OSPFv2-0 The administrative and operational states for the OSPF protocol
RIP The administrative and operational states for the RIP protocol
ISIS The administrative and operational states for the IS-IS protocol
MPLS The administrative and operational states for the MPLS protocol
RSVP The administrative and operational states for the RSVP protocol
LDP The administrative and operational states for the LDP protocol
BGP The administrative and operational states for the BGP protocol
Max IPv4 Routes The maximum number of IPv4 routes configured for the system
Max IPv6 Routes The maximum number of IPv6 routes configured for the system
Total IPv4 Routes The number of IPv4 routes in the route table
Total IPv6 Routes The number of IPv6 routes in the route table
ECMP Max Routes The number of ECMP routes configured for path sharing
Triggered Policies No — triggered route policy re-evaluation is disabled
Yes — triggered route policy re-evaluation is enabled
