IP Router Configuration
7705 SAR OS Router Configuration Guide 193
Parameters ip-address — displays the static ARP entry associated with the specified IP address
ip-int-name — displays the static ARP entry associated with the specified IP interface name
ieee-mac-addr — displays the static ARP entry associated with the specified MAC address
Output The following output is an example of the static ARP table, and Table 35 describes the fields.
Sample Output
*A:ALU-A# show router static-arp
===============================================================================
ARP Table
===============================================================================
IP Address MAC Address Expiry Type Interface
-------------------------------------------------------------------------------
10.200.0.253 00:00:5a:40:00:01 00:00:00 Sta to-ser1
12.200.1.1 00:00:5a:01:00:33 00:00:00 Inv to-ser1a
-------------------------------------------------------------------------------
No. of ARP Entries: 1
===============================================================================
*A:ALU-A#
*A:ALU-A# show router static-arp 12.200.1.1
===============================================================================
ARP Table
===============================================================================
IP Address MAC Address Expiry Type Interface
-------------------------------------------------------------------------------
12.200.1.1 00:00:5a:01:00:33 00:00:00 Inv to-ser1
===============================================================================
*A:ALU-A#
Note: Multiple MAC addresses can be associated with an interface that is a network port.
Table 35: Show Static ARP Table Output Fields
Label Description
IP Address The IP address of the static ARP entry
MAC Address The MAC address of the static ARP entry
Expiry The age of the ARP entry. Static ARPs always have 00:00:00 for the
age.
Type Inv — the ARP entry is an inactive static ARP entry (invalid)
Sta — the ARP entry is an active static ARP entry
