Getting to know your telephone
8AL91432ENAD ed01.1 8/94
6
Status Led indicator / Ambiant light sensor
Flashing blue:default incoming calls.
Flashing orange (manager/assistant): as assistant, manager’s incoming call.
Flashing purple (supervisor): as supervisor, supervisee’s incoming call.
7
Navigation.
8
Wired handset (wideband in IP mode, narrow band in Digital mode).
9
loudspeaker.
10
Microphone.
11
USB-A connector.
12
2-degree adjustable foot (55°,40°).
(1)
these predefined keys depend on the system and the countries, contact your installer for more
information about your system (configuration for United States for example).
1.3 Unboxing
Deskphone
Handset
2-degree adjustable foot
Handset cord
Safety and regulatory
instructions

