21 Operating data and performance
Operating data 21.1
Operating data
Heating
medium
Heating
circuit
Hot water
circuit
Design pressure, MPa
1,0 (1,6)
1)
1,0
1,0
Design temperature, °C
100 (120)
1)
100
100
Opening pressure,
safety valve, MPa
0,9
Volume, l
0,34
---
0,36 (0,38)
2)
1)
AquaMicro
2)
Micro HTC
AquaMicro 21.1.1
Performance at available differential pressure 50-600 kPa
Designed
temperature
programme (°C)
Capacity
(kW)
Primary
flow
(l/s)
Actual
return temp.
(°C)
Secondary
flow
(l/s)
Hot water circuit
80-25/10-55
79
0,34
25
0,42
70-25/10-58
36
0,19
25
0,18
65-25/10-50
55
0,33
25
0,33
Micro DPC, Micro RTC, Micro HTC, Micro STC, Micro STC2 21.1.2
Performance at available differential pressure 50-400 kPa
Designed
temperature
programme (°C)
Capacity
(kW)
Primary
flow
(l/s)
Actual
return temp.
(°C)
Secondary
flow
(l/s)
Hot water circuit
Micro DPC, Micro RTC, (Micro HTC), Micro STC, Micro STC2
80-25/10-55
79 (66)
0,34 (0,29)
25
0,42 (0,35)
70-25/10-58
36 (29)
0,19 (0,15)
25
0,18 (0,14)
65-25/10-50
55 (46)
0,33 (0,28)
25
0,33 (0,28)
Heating Circuit 1
Micro DPC, Micro RTC (Micro HTC)
80-50 (80-60)
10
0,08 (0,12)
50 (60)
0,08 (0,12)
Heating circuit 1
Micro STC, Micro STC2
80-50/50-70
10
0,08
50
0,12
80-60/60-70
7
0,08
60
0,16
80-45/45-60
12
0,08
45
0,19
80-30/30-35
7
0,03
30
0,33
Heating circuit 2
Micro STC2
80-50
10
0,08
50
0,08
