ALLEN & HEATH CQ-12T User Manual

 58
User Guide V1.1.0 Issue 1
Recall Processing Parameters Using Libraries
1.
Go to PROCESSING, locate the bank of faders from
the top of the screen containing the channel where
the processing will be recalled to.
2.
Select the channel, then stay in bank view to recall
processing for a whole channel or select a
processing block (e.g. Compressor) to view it in
detail and recall only that part of the processing.
3.
Open the Library from the top right-hand corner of
the screen. A different library will open depending
on the screen currently being viewed.
Switch between Factory and User Libraries to
choose whether to view Library items in the mixer
(Factory) or those stored by the User in the
currently loaded Show.
6.
Select an item from the list then use Recall to
replace the current settings of the channel or
processing block with the stored settings.
 Whole channel libraries can also be accessed from the CONFIG / INPUTS and
CONFIG / OUTPUTS screens. From here a recall will also include settings from the
config screen e.g. name and preamp gain.

ALLEN & HEATH CQ-12T Specifications

General

Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Frequency range	20 - 20000 Hz
Channels quantity	12 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Built-in display	Yes
Output impedance	75 Ω
Compatible memory cards	SD
XLR out	2
RJ-45 ports quantity	1
Number of microphone inputs	10
DJ mixer	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	291 mm
Height	89 mm
Weight	2400 g
Package depth	305 mm
Package width	370 mm
Package height	190 mm
Package weight	3200 g
