ALLEN & HEATH CQ-12T User Manual

 59
User Guide V1.1.0 Issue 1
Store/Recall show files
 Show files can only be stored and recalled from/to a connected USB-A storage
device which has been formatted correctly using the HOME / SYSTEM / USB/SD
(Symbols) screen.
1.
Connect a USB Drive to the USB-A port of
the unit.
2.
Go to HOME / DATA / SHOWS.
3.
Use Store New to store the current state of
the CQ along with all Scenes and Libraries
to the inserted USB drive as a new Show.
6.
Select an existing Show and use Overwrite
to replace the contents of the selected
Show on the drive with the current state of
the CQ along with all Scenes and Libraries.
4.
Select Rename to change the name of the
selected show file on the drive.
5.
Select Delete to remove the selected show
file from the USB drive.
8.
Select a Show on the drive and use Recall
to load all settings of the selected Show
into the CQ.
 Note that any current settings will be
overwritten and this cannot be undone, so
it is best practice to Store all current
settings to a Show as a backup before
Recalling another one.

ALLEN & HEATH CQ-12T Specifications

General

Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Frequency range	20 - 20000 Hz
Channels quantity	12 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Built-in display	Yes
Output impedance	75 Ω
Compatible memory cards	SD
XLR out	2
RJ-45 ports quantity	1
Number of microphone inputs	10
DJ mixer	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	291 mm
Height	89 mm
Weight	2400 g
Package depth	305 mm
Package width	370 mm
Package height	190 mm
Package weight	3200 g
