Publication 1734-UM011A-EN-P - February 2004
C-14 1734-POINT I/O Module/RSLogix 5000 Controller Tag Reference
1734-IR2
2 Channel RTD Input
Configuration Data Data Type Default Value Valid Data Values
Low Engineering Channel 0 INT 1,000 -32,768 to 32,767
High Engineering Channel 0 INT 5,000 -32,768 to 32,767
Digital Filter Channel 0 INT 0 0 to 10,000 ms
Low Alarm Limit Channel 0 INT -32,768 -32,768 to 32,767
High Alarm Limit Channel 0 INT 32,767 -32,768 to 32,767
Low Low Alarm Limit Channel 0 INT -32,768 -32,768 to 32,767
High High Alarm Limit Channel 0 INT 32,767 -32,768 to 32,767
Limit Alarm Latch Channel 0 SINT 0 0=No Latching
1=Alarms Latch
Alarm Disable Channel 0 SINT 0 0=Alarms Enabled
1=Alarms Disabled
Sensor Type Channel 0 SINT 1 0=Ohms
1=100 Ω Pt α385
2=200 Ω Pt α385
5=100 Ω JPt α3916
6=200 Ω JPt α3916
9=10 Ω Cu α427
10=120 Ω Ni α672
11=100 Ω Ni α618
12=120 Ω Ni α618
Temperature Mode Channel 0 SINT 1 0=Custom Scale
1=°C
2=°F
3=°K
4=°R
Low Engineering Channel 1 INT 1,000 -32,768 to 32,767
High Engineering Channel 1 INT 5,000 -32,768 to 32,767
Digital Filter Channel 1 INT 0 0 to 10,000 ms
Low Alarm Limit Channel 1 INT -32,768 -32,768 to 32,767
High Alarm Limit Channel 1 INT 32,767 -32,768 to 32,767
Low Low Alarm Limit Channel 1 INT -32,768 -32,768 to 32,767
High High Alarm Limit Channel 1 INT 32,767 -32,768 to 32,767
Limit Alarm Latch Channel 1 SINT 0 0=No Latching
1=Alarms Latch
Alarm Disable Channel 1 SINT 0 0=Alarms Enabled
1=Alarms Disabled
