Publication 1734-UM011A-EN-P - February 2004
1734-POINT I/O Module/RSLogix 5000 Controller Tag Reference C-15
1734-IR2
2 Channel RTD Input
Configuration Data Data Type Default Value Valid Data Values
Sensor Type Channel 1 SINT 1 0=Ohms
1=100 Ω Pt α385
2=200 Ω Pt α385
5=100 Ω JPt α3916
6=200 Ω JPt α3916
9=10 Ω Cu α427
10=120 Ω Ni α672
11=100 Ω Ni α618
12=120 Ω Ni α618
Temperature Mode Channel 1 SINT 1 0=Custom Scale
1=°C
2=°F
3=°K
4=°R
Notch Filter (Channel 0 & 1) SINT 1 0=50Hz
1=60Hz
2=100Hz
3=120Hz
4=200Hz
5=240Hz
6=300Hz
7=400Hz
8=480Hz
Input Data Data Type Default Value Valid Data Values
Data Channel 0 INT 0 -32,768 to 32,767
Data Channel 1 INT 0 -32,768 to 32,767
Status Byte Channel 0 SINT 0 Bit 0 Fault
Bit 1 Calibration
Bit 2 LowAlarm
Bit 3 HighAlarm
Bit 4 LowLowAlarm
Bit 5 HighHighAlarm
Bit 6 Underrange
Bit 7 Overrange
Status Byte Channel 1 SINT 0 Bit 0 Fault
Bit 1 Calibration
Bit 2 LowAlarm
Bit 3 HighAlarm
Bit 4 LowLowAlarm
Bit 5 HighHighAlarm
Bit 6 Underrange
Bit 7 Overrange
Output Data Data Type Default Value Valid Data Values
None
