Allen-Bradley Rockwell Automation 1734-AENT User Manua

Publication 1734-UM011A-EN-P - February 2004
1734-POINT I/O Module/RSLogix 5000 Controller Tag Reference C-17
1734-IT2
2 Channel Thermocouple Input, Isol.
Configuration Data Data Type Default
Value
Valid Data Values
Temperature Mode Channel 0 SINT 1 0=mV/Custom Scale
1=°C
2=°F
3=°K
4=°R
Cold Junction Enable Channel 0 SINT 1 0=Disabled
1=Enabled
Cold Junction Offset Channel 0 INT 0 0 to 7,000 (0.00-70.00)
Low Engineering Channel 1 INT 0 -32,768 to 32,767
High Engineering Channel 1 INT 7,000 -32,768 to 32,767
Alarm Disable Channel 1 SINT 0 0=Alarms Enabled
1=Alarms Disabled
Limit Alarm Latch Channel 1 SINT 0 0=No Latching
1=Alarms Latch
Notch Filter Channel 1 SINT 1 0=50Hz
1=60Hz
2=100Hz
3=120Hz
4=200Hz
5=240Hz
6=300Hz
7=400Hz
8=480Hz
Sensor Type Channel 1 SINT 5 0=mV
1=B
2=C
3=E
4=J
5=K
6=N
7=R
8=S
9=T
Digital Filter Channel 1 INT 0 0 to 10,000 ms
Low Alarm Limit Channel 1 INT -32,768 -32,768 to 32,767
High Alarm Limit Channel 1 INT 32,767 -32,768 to 32,767
Low Low Alarm Limit Channel 1 INT -32,768 -32,768 to 32,767
High High Alarm Limit Channel 1 INT 32,767 -32,768 to 32,767

Allen-Bradley Rockwell Automation 1734-AENT Specifications

General

Model	1734-AENT
Category	Network Hardware
Type	EtherNet/IP Adapter
Ethernet Ports	2
IP Addressing	Static or DHCP
Network Address	Configurable via software
Mounting	DIN rail
Number of Ports	2
Port Type	RJ45
Communication Protocol	EtherNet/IP
Manufacturer	Rockwell Automation
Power Supply	24V DC
Enclosure	Open-style
