Allen-Bradley Rockwell Automation 1734-AENT User Manua

Publication 1734-UM011A-EN-P - February 2004
C-18 1734-POINT I/O Module/RSLogix 5000 Controller Tag Reference
1734-IT2
2 Channel Thermocouple Input, Isol.
Configuration Data Data Type Default
Value
Valid Data Values
Temperature Mode Channel 1 SINT 1 0=mV/Custom Scale
1=°C
2=°F
3=°K
4=°R
Cold Junction Enable Channel 1 SINT 1 0=Disabled
1=Enabled
Cold Junction Offset Channel 1 INT 0 0 to 7,000 (0.00-70.00)
Input Data Data Type Default
Value
Valid Data Values
Data Channel 0 INT 0 -32,768 to 32,767
Data Channel 1 INT 0 -32,768 to 32,767
Status Byte Channel 0 SINT 0 Bit 0 Fault
Bit 1 Calibration
Bit 2 LowAlarm
Bit 3 HighAlarm
Bit 4 LowLowAlarm
Bit 5 HighHighAlarm
Bit 6 Underrange
Bit 7 Overrange
Status Byte Channel 1 SINT 0 Bit 0 Fault
Bit 1 Calibration
Bit 2 LowAlarm
Bit 3 HighAlarm
Bit 4 LowLowAlarm
Bit 5 HighHighAlarm
Bit 6 Underrange
Bit 7 Overrange
Cold Junction Data INT 0 -32,768 to 32,767
Output Data Data Type Default
Value
Valid Data Values
None

Allen-Bradley Rockwell Automation 1734-AENT Specifications

General

Model	1734-AENT
Category	Network Hardware
Type	EtherNet/IP Adapter
Ethernet Ports	2
IP Addressing	Static or DHCP
Network Address	Configurable via software
Mounting	DIN rail
Number of Ports	2
Port Type	RJ45
Communication Protocol	EtherNet/IP
Manufacturer	Rockwell Automation
Power Supply	24V DC
Enclosure	Open-style
