Allen-Bradley Rockwell Automation 1734-AENT User Manua

Publication 1734-UM011A-EN-P - February 2004
Preface 2
How To Use This Manual
This manual contains an overview of the 1734-AENT adapter. It describes
how to install and configure the adapter, and provides examples showing how
to use the adapter to communicate with POINT I/O over an EtherNet/IP
network.
About the Example Applications
This manual presents two example applications that demonstrate the
procedures for configuring and communicating with POINT I/O using the
1734-AENT adapter. The example applications are intended as building blocks
to help you get your own system up and running. We recommend that you set
up and run the example applications and use them as guides.
Here is the type of system you’ll be setting up:
TIP
This symbol identifies helpful tips.
Local
Chassis
POINT I/O
Logix5555
Controller (slot 1)
1756-ENBT
10.88.70.4 (slot 3)
Data
Switch
10.88.70.26
Programming
Terminal
Slot 0 1 2 3
1734-AENT
10.88.70.2
Slot 0 1 2 3 4
31393-M

Allen-Bradley Rockwell Automation 1734-AENT Specifications

General

Model	1734-AENT
Category	Network Hardware
Type	EtherNet/IP Adapter
Ethernet Ports	2
IP Addressing	Static or DHCP
Network Address	Configurable via software
Mounting	DIN rail
Number of Ports	2
Port Type	RJ45
Communication Protocol	EtherNet/IP
Manufacturer	Rockwell Automation
Power Supply	24V DC
Enclosure	Open-style
