System Components
We used the following components for the example applications. You will
need the same or similar components to set up your own control system using
PONT I/O on EtherNet/IP.
Quantity Product Name Catalog Number Part Number
Hardware
1 POINT I/O EtherNet/IP Adapter 1734-AENT
1 POINT I/O 24V dc Sink Output Module 1734-OV4E/C
1 POINT I/O Relay Output Module 1734-OW2/C
1 DIN Rail 199-DR1 or equivalent
1 ControlLogix chassis 1756-A4, (or -A7, -A13, -A17)
1 ControlLogix power supply 1756-PA72, (or -PB72)
1 Logix5555 controller 1756-L55
1 ControlLogix EtherNet/IP Bridge Module 1756-ENBT
1 Personal computer that supports
RSLogix 5000 software
Any appropriate model running Windows
NT 4.0, Service Pack 6A or higher
1 Ethernet switch Refer to manufacturer’s specifications
1 24V dc power supply 1734-EP24DC
Associated media and connectors as needed
Software
1 RSLinx communications software,
V2.31.00 or higher
9355-WAB, -WABOEM, -WABC
1 RSLogix 5000 programming software,
V11.11 or higher
9324-RLD300ENE
