Allen-Bradley Rockwell Automation 1734-AENT User Manua

Publication 1734-UM011A-EN-P - February 2004
Preface 4
Where to Find
More Information
Refer to the following Rockwell publications as needed for additional help
when setting up and using your EtherNet/IP network.
For information about See this publication Publication number
Using EtherNet/IP for industrial control EtherNet/IP Performance and Application Guide ENET-AP001
EtherNet/IP media EtherNet/IP Media Planning and Installation Guide ENET-IN001
Ethernet communication interface
modules
Ethernet Communication Interface Module Installation
Instructions
1756-5.3
Ethernet Communication Interface Module User Manual 1756-6.5.1
Ethernet Communication Interface Module Installation
Instructions
1756-IN053
Ethernet Communication Interface Module User Manual 1756-UM051
Ethernet Communication Interface Module Release Notes 1756-RN053
ControlLogix chassis ControlLogix Chassis Installation instructions 1756-IN080 (Series B)
ControlLogix power supplies ControlLogix Power Supplies Installation Instructions 1756-5.67 (PA72/PB72)
1756-5.78 (PA75/PB75)
Logix5555 programmable controllers Logix5555 Controller User Manual 1756-UM523
SoftLogix5800 Controller SoftLogix5800 User Manual 1789-UM002 (L10, L30, L60)
1789-UM001 (SL5, SL51, SL52)
ControlLogix EtherNet/IP bridge module
with firmware version 2.3 or higher
ControlLogix EtherNet/IP Bridge Module Installation Instructions 1756-IN019
ControlLogix EtherNet/IP Bridge Module User Manual 1756-UM050
RSLogix 5000 programming software Getting Results with RSLogix 5000, version 3.2.1 or higher 9399-RLD300GR
RSLinx communications software RSLinx Lite User’s Guide 9399-WAB32LUG
1734-AENT Adapter POINT I/O EtherNet/IP Adapter Installation Instructions 1734-IN590
POINT I/O DeviceNet Adapter POINT I/O Quick Start 1734-QS001
POINT I/O digital and analog modules
and PointBLOCK I/O modules
POINT I/O Digital and Analog Modules and PointBLOCK I/O
Modules User Manual
1734-UM001
POINT I/O input and output modules POINT I/O Technical Data 1734-TD002
POINT I/O interface modules POINT I/O RS-232 ASCII Module User Manual 1734-UM009
POINT I/O RS-232 ASCII Module Installation Instructions 1734-IN588
POINT I/O expansion power supply POINT I/O 24V dc Expansion Power Supply Installation
Instructions
1734-IN058
POINT I/O field potential distributor POINT I/O Field Potential Distributor Installation Instructions 1734-IN059
POINT I/O input modules POINT I/O 120V ac Input Module Installation Instructions 1734-IN010
POINT I/O Input Module Installation Instructions 1734-IN051
POINT I/O input analog modules POINT I/O 2-Input Analog Module Installation Instructions 1734-IN053
POINT I/O 2 Voltage Input Analog Module Installation Instructions 1734-IN001
POINT I/O encoders/counter modules POINT I/O Encoders/Counter Module User Manual 1734-UM006
POINT I/O 5V Encoders/Counter Module Installation Instructions 1734-IN005
POINT I/O 24V Encoders/Counter Module Installation Instructions 1734-IN006

Allen-Bradley Rockwell Automation 1734-AENT Specifications

General

Model	1734-AENT
Category	Network Hardware
Type	EtherNet/IP Adapter
Ethernet Ports	2
IP Addressing	Static or DHCP
Network Address	Configurable via software
Mounting	DIN rail
Number of Ports	2
Port Type	RJ45
Communication Protocol	EtherNet/IP
Manufacturer	Rockwell Automation
Power Supply	24V DC
Enclosure	Open-style
