Publication 1734-UM011A-EN-P - February 2004
7-4
Surge Transient
Immunity
IEC 61000-4-5:
+
1kV line-line(DM) and +2kV line-earth(CM) on signal
ports
+
1kV line-line(DM) and +2kV line-earth(CM) on power
ports
Conducted RF
Immunity
IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to
80MHz
Emissions CISPR 11:
Group 1, Class A
Enclosure Type Rating None (open-style)
Conductors
Wire Size
Category
14- 22 AWG (2.5-0.25mm
2
) solid or stranded wire rated
at 75
o
C or higher
3/64 inch (1.2mm) insulation maximum
2
1
Ethernet Connector RJ-45, Category 5
Terminal Base Screw
Torque
7 pound-inches (0.8Nm)
Mass 9.0 oz/255 grams
Certifications
(when product is marked)
C-UL-US UL Listed Industrial Control Equipment,
certified for US and Canada
C-UL-US UL Listed for Class I, Division 2, Groups A,
B, C, and D Hazardous locations, certified for
US and Canada
CE
2
European Union 89/336/EEC EMC Directive,
compliant with:
EN 61000-6-4; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial
Requirements
EN 61000-6-2; Industrial Immunity
C-Tick
2
Australian Radiocommunications Act,
compliant with:
AS/NZS CISPR 11; Industrial Emissions
ODVA ODVA conformance tested to EtherNet/IP
specifications
1 Use this conductor category information for planning conductor routing as described in publication 1770-4.1,
“Industrial Automation Wiring and Grounding Guidelines.”
2 See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates, and other
certification details.
