Install Stratix 5700 Switches Chapter 5
Be sure that you cannot see any wire lead. Only wire with insulation can
extend from the connector.
7. Use a ratcheting-torque screwdriver to torque the captive screws of the
power connector to 0.23 N•m (2.0 lb•in).
Do not exceed the recommended torque.
ATTENTION: An exposed wire lead from a DC input power source can
conduct harmful levels of electricity. Be sure that no exposed portion
of the DC input power source wire extends from the connectors or
terminal blocks.
32279-M
32281-M
