Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 439
Data Types Appendix A
16-port Gigabit Switches
Catalog number 1783-HMS4SG8EG4CGN, 1783-HMS4SG8EG4CGR
PortFa1_14Disable BOOL Decimal DisablePort:14
PortFa1_15Disable BOOL Decimal DisablePort:15
PortFa1_16Disable BOOL Decimal DisablePort:16
Table 129 - Input Data Type (16-port Gb switches)
AB:STRATIX_5400_16PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortGi1_1Connected BOOL Decimal LinkStatus:1
PortGi1_2Connected BOOL Decimal LinkStatus:2
PortGi1_3Connected BOOL Decimal LinkStatus:3
PortGi1_4Connected BOOL Decimal LinkStatus:4
PortGi1_5Connected BOOL Decimal LinkStatus:5
PortGi1_6Connected BOOL Decimal LinkStatus:6
PortGi1_7Connected BOOL Decimal LinkStatus:7
PortGi1_8Connected BOOL Decimal LinkStatus:8
PortGi1_9Connected BOOL Decimal LinkStatus:9
PortGi1_10Connected BOOL Decimal LinkStatus:10
PortGi1_11Connected BOOL Decimal LinkStatus:11
PortGi1_12Connected BOOL Decimal LinkStatus:12
PortGi1_13Connected BOOL Decimal LinkStatus:13
PortGi1_14Connected BOOL Decimal LinkStatus:14
PortGi1_15Connected BOOL Decimal LinkStatus:15
PortGi1_16Connected BOOL Decimal LinkStatus:16
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortGi1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortGi1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortGi1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortGi1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortGi1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortGi1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortGi1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
Table 128 - Output Data Type (16-port switches) (continued)
AB:STRATIX_5400_16PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
