458 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
10-port Gb Switches
Catalog numbers 1783-BMS10CGL, 1783-BMS10CGA, 1783-
BMS10CGN, 1783-BMS10CGP, 1783-ZMS4T4E2TGN, 1783-
ZMS4T4E2TGP
PortFa1_7Utilization SINT Decimal
PortFa1_8Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 142 - Output Data Type (8-port switches)
AB:STRATIX_5700_8PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortFa1_1Disable BOOL Decimal DisablePort:1
PortFa1_2Disable BOOL Decimal DisablePort:2
PortFa1_3Disable BOOL Decimal DisablePort:3
PortFa1_4Disable BOOL Decimal DisablePort:4
PortFa1_5Disable BOOL Decimal DisablePort:5
PortFa1_6Disable BOOL Decimal DisablePort:6
PortFa1_7Disable BOOL Decimal DisablePort:7
PortFa1_8Disable BOOL Decimal DisablePort:8
Table 143 - Input Data Type (10-port Gb switches)
AB:STRATIX_5700_10PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:7
PortFa1_8Connected BOOL Decimal LinkStatus:8
Table 141 - Input Data Type (8-port switches) (continued)
AB:STRATIX_5700_8PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
