Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 459
Data Types Appendix A
PortGi1_1Connected BOOL Decimal LinkStatus:9
PortGi1_2Connected BOOL Decimal LinkStatus:10
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortFa1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortFa1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortFa1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortFa1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
PortFa1_8UnauthorizedDevice BOOL Decimal UnauthorizedDevice:8
PortGi1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:9
PortGi1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:10
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortFa1_1Threshold BOOL Decimal ThresholdExceeded:1
PortFa1_2Threshold BOOL Decimal ThresholdExceeded:2
PortFa1_3Threshold BOOL Decimal ThresholdExceeded:3
PortFa1_4Threshold BOOL Decimal ThresholdExceeded:4
PortFa1_5Threshold BOOL Decimal ThresholdExceeded:5
PortFa1_6Threshold BOOL Decimal ThresholdExceeded:6
PortFa1_7Threshold BOOL Decimal ThresholdExceeded:7
PortFa1_8Threshold BOOL Decimal ThresholdExceeded:8
PortGi1_1Threshold BOOL Decimal ThresholdExceeded:9
PortGi1_2Threshold BOOL Decimal ThresholdExceeded:10
AllPortsUtilization SINT Decimal
PortFa1_1Utilization SINT Decimal
PortFa1_2Utilization SINT Decimal
PortFa1_3Utilization SINT Decimal
PortFa1_4Utilization SINT Decimal
PortFa1_5Utilization SINT Decimal
PortFa1_6Utilization SINT Decimal
PortFa1_7Utilization SINT Decimal
PortFa1_8Utilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 143 - Input Data Type (10-port Gb switches) (continued)
AB:STRATIX_5700_10PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
