28 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 1 About the Switches
Stratix 8000 and 8300 Templates
The following SDM templates are recommended:
•Default
• Lanbase Routing
For static and connected routing, or if you have more than 180 IGMP groups
or multicast routes, you can use the Lanbase Routing template. Other SDM
templates are available, but are not covered in detail.
You can use SDM templates for IP Version 4 (IPv4) to optimize these features.
Table 9 - Stratix 8000 and ArmorStratix 8300 Templates
Feature Memory Allocation
Default Lanbase Routing
Unicast MAC addresses 8K 4K
IPv4 IGMP groups + multicast routes 0.25K 0.25K
IPv4 unicast routes 0 0.75
Directly connected IPv4 hosts 0 0.75
Indirect IPv4 routes 0 16
IPv4 policy-based routing ACEs 0 0
IPv4/MAC QoS ACEs 0.375K 0.375K
IPv4/MAC security ACEs 0.375K 0.375K
