Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 487
Appendix B
Port Assignments for CIP Data
The following tables identify the instance numbers of the Ethernet link objects
that are associated with each port on the switch. Instance 0 does not apply to all
ports as it does for bit maps.
The bit numbers identify each port when they are contained in a structure of
all ports, such as in the output assembly. Bit 0 refers to any or all ports.
Topic Page
Stratix 5400 Port Assignments 488
Stratix 5410 Port Assignments 490
Stratix 5700 Port Assignments 491
ArmorStratix 5700 Port Assignments 492
Stratix 8000 and 8300 Port Assignments 493
