Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 539
Cables and Connectors Appendix D
The following table lists the pinouts for the console port, RJ45-to-DB-25
female DTE adapter, and the console device.
The RJ45-to-DB-25 female DTE adapter is not supplied with the switch.
PoE Port Cable Specifications
For PoE ports, use a Category 5 (Cat 5) cable with a distance of up to 100 m
(328 ft).
Table 174 - Pinouts with DB-25 Pin
Switch Console Port (DTE) RJ45-to-DB-25 Terminal Adapter Console Device
Signal DB-25 Pin Signal
RTS 5 CTS
DTR 6 DSR
TxD 3 RxD
GND 7 GND
GND 7 GND
RxD 2 TxD
DSR 20 DTR
CTS 4 RTS
