Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 157
Chapter 6
Install Stratix 8000 and 8300 Switches
Topic Page
Specifications 159
Overview 160
Parts List and Required Tools 162
Attach Expansion Modules 164
Mount the Switch 166
Install an SFP Module 169
Ground the Switch 171
Wire the DC Power Source for the Switch 172
Wire the DC Power Source for the PoE Expansion Module 174
Attach the Power and Relay Connector to the Switch to the Switch 176
Attach the Power Connector to the PoE Expansion Module 178
Wire External Alarms 178
Connect to 10/100 Copper Ports 180
Connect to a PoE Expansion Module Port 180
Connect to Dual-purpose Uplink Ports 181
Connect to 100BaseFX Ports 182
Install or Remove the CompactFlash Card 182
ATTENTION: Environment and Enclosure
This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as
defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating.
This equipment is not intended for use in residential environments and may not provide adequate protection to radio
communication services in such environments.
This equipment is supplied as open-type equipment. It must be mounted within an enclosure that is suitably designed for those
specific environmental conditions that will be present and appropriately designed to prevent personal injury resulting from
accessibility to live parts. The enclosure must have suitable flame-retardant properties to prevent or minimize the spread of flame,
complying with a flame spread rating of 5VA or be approved for the application if nonmetallic. The interior of the enclosure must be
accessible only by the use of a tool. Subsequent sections of this publication may contain additional information regarding specific
enclosure type ratings that are required to comply with certain product safety certifications.
In addition to this publication, see the following:
• Industrial Automation Wiring and Grounding Guidelines, publication
1770-4.1, for additional installation requirements
• NEMA Standard 250 and IEC 60529, as applicable, for explanations of the degrees of protection provided by enclosures
