434 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
12-port Gigabit Switches
Catalog numbers 1783-HMS8TG4CGN, 1783-HMS8SG4CGN,
1783-HMS4EG8CGN, 1783-HMS8TG4CGR, 1783-HMS8SG4CGR,
1783-HMS4EG8CGR
PortFa1_10Disable BOOL Decimal DisablePort:10
PortFa1_11Disable BOOL Decimal DisablePort:11
PortFa1_12Disable BOOL Decimal DisablePort:12
Table 125 - Input Data Types (12-port Gb switches)
AB:STRATIX_5400_12PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortGi1_1Connected BOOL Decimal LinkStatus:1
PortGi1_2Connected BOOL Decimal LinkStatus:2
PortGi1_3Connected BOOL Decimal LinkStatus:3
PortGi1_4Connected BOOL Decimal LinkStatus:4
PortGi1_5Connected BOOL Decimal LinkStatus:5
PortGi1_6Connected BOOL Decimal LinkStatus:6
PortGi1_7Connected BOOL Decimal LinkStatus:7
PortGi1_8Connected BOOL Decimal LinkStatus:8
PortGi1_9Connected BOOL Decimal LinkStatus:9
PortGi1_10Connected BOOL Decimal LinkStatus:10
PortGi1_11Connected BOOL Decimal LinkStatus:11
PortGi1_12Connected BOOL Decimal LinkStatus:12
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortGi1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortGi1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortGi1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortGi1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortGi1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortGi1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortGi1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
PortGi1_8UnauthorizedDevice BOOL Decimal UnauthorizedDevice:8
PortGi1_9UnauthorizedDevice BOOL Decimal UnauthorizedDevice:9
PortGi1_10UnauthorizedDevice BOOL Decimal UnauthorizedDevice:10
Table 124 - Output Data Type (12-port switches) (continued)
AB:STRATIX_5400_12PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
