Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 435
Data Types Appendix A
PortGi1_11UnauthorizedDevice BOOL Decimal UnauthorizedDevice:11
PortGi1_12UnauthorizedDevice BOOL Decimal UnauthorizedDevice:12
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortGi1_1Threshold BOOL Decimal ThresholdExceeded:1
PortGi1_2Threshold BOOL Decimal ThresholdExceeded:2
PortGi1_3Threshold BOOL Decimal ThresholdExceeded:3
PortGi1_4Threshold BOOL Decimal ThresholdExceeded:4
PortGi1_5Threshold BOOL Decimal ThresholdExceeded:5
PortGi1_6Threshold BOOL Decimal ThresholdExceeded:6
PortGi1_7Threshold BOOL Decimal ThresholdExceeded:7
PortGi1_8Threshold BOOL Decimal ThresholdExceeded:8
PortGi1_9Threshold BOOL Decimal ThresholdExceeded:9
PortGi1_10Threshold BOOL Decimal ThresholdExceeded:10
PortGi1_11Threshold BOOL Decimal ThresholdExceeded:11
PortGi1_12Threshold BOOL Decimal ThresholdExceeded:12
AllPortsUtilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
PortGi1_3Utilization SINT Decimal
PortGi1_4Utilization SINT Decimal
PortGi1_5Utilization SINT Decimal
PortGi1_6Utilization SINT Decimal
PortGi1_7Utilization SINT Decimal
PortGi1_8Utilization SINT Decimal
PortGi1_9Utilization SINT Decimal
PortGi1_10Utilization SINT Decimal
PortGi1_11Utilization SINT Decimal
PortGi1_12Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MinorAlarmRelay BOOL Decimal AlarmRelay:1
MulticastGroupActive DINT Binary
Table 125 - Input Data Types (12-port Gb switches) (continued)
AB:STRATIX_5400_12PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
