376 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 8 Monitor the Switch
Off No link present on the port.
Solid green Port link; no activity.
Flashing green and off Link is active and healthy.
Alternating green and
amber
There is a fault or error on the link.
Solid amber The port is disabled.
Duplex In Duplex mode, the port status indicators show the Duplex mode (Full-duplex or Half-duplex) of the ports. The 10/100/1000 ports operate only in Full-duplex
mode.
Off The port is not operating.
Solid amber The port is operating in Half-duplex mode.
Solid green The port is operating in Full duplex mode.
Speed In Speed mode, the port status indicators show the operating speed of the ports.
Off The port is not operating.
Solid amber The port is operating at 10 Mbps.
Solid green The port is operating at 100 Mbps.
Flashing green The port is operating at 1000 Mbps.
Power In Power mode, the port status indicators show the status of PoE on switch models with PoE capability.
Off PoE is disabled on the port.
Solid green PoE is enabled on the port. The switch port is providing power.
Flashing green and
amber
PoE is denied because it exceeds the power capacity of the switch.
Flashing amber PoE is denied because it exceeds the configured power limit for the switch port.
Table 96 - Stratix 5700 and ArmorStratix 5700 Port Status Indicators (continued)
Mode Status Description
