Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 441
Data Types Appendix A
PortGi1_12Utilization SINT Decimal
PortGi1_13Utilization SINT Decimal
PortGi1_14Utilization SINT Decimal
PortGi1_15Utilization SINT Decimal
PortGi1_16Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MinorAlarmRelay BOOL Decimal AlarmRelay:1
MulticastGroupActive DINT Binary
Table 130 - Output Data Type (16-port Gb switches)
AB:STRATIX_5400_16PORT_GB_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortGi1_1Disable BOOL Decimal DisablePort:1
PortGi1_2Disable BOOL Decimal DisablePort:2
PortGi1_3Disable BOOL Decimal DisablePort:3
PortGi1_4Disable BOOL Decimal DisablePort:4
PortGi1_5Disable BOOL Decimal DisablePort:5
PortGi1_6Disable BOOL Decimal DisablePort:6
PortGi1_7Disable BOOL Decimal DisablePort:7
PortGi1_8Disable BOOL Decimal DisablePort:8
PortGi1_9Disable BOOL Decimal DisablePort:9
PortGi1_10Disable BOOL Decimal DisablePort:10
PortGi1_11Disable BOOL Decimal DisablePort:11
PortGi1_12Disable BOOL Decimal DisablePort:12
PortGi1_13Disable BOOL Decimal DisablePort:13
PortGi1_14Disable BOOL Decimal DisablePort:14
PortGi1_15Disable BOOL Decimal DisablePort:15
PortGi1_16Disable BOOL Decimal DisablePort:16
Table 129 - Input Data Type (16-port Gb switches) (continued)
AB:STRATIX_5400_16PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
