Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 503

Port Numbering Appendix C

1783-HMS8TG8EG4CGR 20-port (8 Gigabit ports; 4 Gigabit combo ports; 8 Gigabit

PoE/PoE+ ports) managed switch; Layer 3 firmware

Gi1/1

Gi1/2

Gi1/3

Gi1/4

Gi1/5

Gi1/6

Gi1/7

Gi1/8

Gi1/9

Gi1/10

Gi1/11

Gi1/12

Gi1/13

Gi1/14

Gi1/15

Gi1/16

Gi1/17

Gi1/18

Gi1/19

Gi1/20

Table 164 - Stratix 5400 Port Numbering (continued)

Cat. No. Description Port Numbering on Switch Labels Port Numbering in config.txt Text File
