Publication 2098-IN003E-EN-P — April 2004
3-20 Connecting Your Ultra3000
Refer to the table below for the catalog number of the motor power
cable for your Ultra3000 drive.
To wire your motor power:
1. Route the motor power cable to your Ultra3000 drive.
2. Using a screw driver, loosen the screw for each of the terminal
locations and attach wires as shown in the table below.
3. Tighten each terminal screw. Refer to the table on page 3-13 for
torque values.
For this motor: This Universal Cable is available:
Use this Motor Power Cable when
Universal Cables are not available:
MP-Series
(Low Inertia and Integrated
Gear) (230V or 460V systems)
2090-XXNPMP-16Sxx
2090-XXNPMP-14Sxx
2090-XXNPMP-10Sxx
2090-XXNPMP-8Sxx
N/A1326AB-Series (M2L/S2L)
MP-Series
(Food Grade)
2090-XXNPMF-16Sxx
2090-XXNPMF-14Sxx
2090-XXNPMF-10Sxx
F-Series
2090-XXNPHF-16Sxx
2090-XXNPHF-14Sxx
2090-UXNPAHF-10Sxx
2090-UXNPAHF-8Sxx
H-Series
2090-XXNPH-16Sxx
2090-XXNPHF-14Sxx
2090-UXNPAHF-10Sxx
2090-UXNPAHF-8Sxx
2090-UXNPAH-6Sxx
N-Series 2090-XXNPN-16Sxx N/A
Y-Series 2090-XXNPY-16Sxx N/A
IMPORTANT
To ensure system performance, run wires and
cables in the wireways as established in
Chapter 1.
Insert the motor power wires from this
servo motor:
Into this
terminal on
TB1:
1326AB- (M2L/S2L), F-,
H-, N-, and MP-Series
Y-Series
U / Brown 1 / Black U
V / Black 2 / Black V
W / Blue 3 / Black W
Green/Yellow Green/Yellow
IMPORTANT
Ensure motor power is wired with proper
phasing relative to the motor terminals. On some
motors, the motor leads may be labeled R, S, and
T which correspond to U, V, and W respectively.
To Next Page
