Catalog Numbers and Accessories C-7
Motor End Connector Kits
Use the following table to identify the motor-end connector kit for
your motor power, feedback, and brake cable.
Motor Series
Motor Connector
Kit
Description
F-4000
9101-0326 Straight Power Connector Kit
9101-0399 Right-Angle Power Connector Kit
F-6000
9101-0327 Straight Power Connector Kit
9101-0400 Right-Angle Power Connector Kit
F-Series
9101-0329 Straight Feedback Connector Kit
9101-0330 Straight Brake Connector Kit
9101-0402 Right-Angle Feedback Connector Kit
9101-0403 Right-Angle Brake Connector Kit
H-2000
9101-0325 Straight Power Connector Kit
9101-0398 Right-Angle Power Connector Kit
H-3000
9101-0325 Straight Power Connector Kit
9101-0398 Right-Angle Power Connector Kit
H-4000
9101-0326 Straight Power Connector Kit
9101-0399 Right-Angle Power Connector Kit
H-6000
9101-0327 Straight Power Connector Kit
9101-0400 Right-Angle Power Connector Kit
H-8000
9101-0328 Straight Power Connector Kit
9101-0401 Right-Angle Power Connector Kit
H-Series
9101-0329 Straight Feedback Connector Kit
9101-0330 Straight Brake Connector Kit
9101-0402 Right-Angle Feedback Connector Kit
9101-0403 Right-Angle Brake Connector Kit
MP-Series and
1326AB (M2L/S2L)
2090-MPPC-S Straight Power Connector Kit
2090-MPPC-08S Straight Power Connector Kit, 10 mm
2
(8 AWG)
2090-MPFC-S Straight Feedback Connector Kit
2090-MPBC-S Straight Brake Connector Kit
N-Series
9101-1557 Straight Power Connector Kit
9101-1558 Straight Feedback Connector Kit
9101-1698 Brake Connector Kit
Y-Series 9106-0066 Straight Power and Feedback Connector Kit
