Publication 2098-IN003E-EN-P — April 2004
1-18 Installing Your Ultra3000
Mounting Your Ultra3000
Drive
The procedures in this section assume you have prepared your panel
and understand how to bond your system. For installation instructions
regarding other equipment and accessories, refer to the instructions
that came with each of the accessories for their specific requirements.
To mount your Ultra3000 drive:
1. Layout the position for the Ultra3000 and accessories in the
enclosure (refer to Establishing Noise Zones for panel layout
recommendations). Mounting hole dimensions for the Ultra3000
are shown in Appendix A.
2. Attach the Ultra3000 to the cabinet, first using the upper mounting
slots of the drive and then the lower. The recommended mounting
hardware is M5 metric (1/4-20) or #10 MS bolts. Observe bonding
techniques as described in HF Bonding Your System.
3. Tighten all mounting fasteners.
ATTENTION
!
This drive contains ESD (Electrostatic Discharge)
sensitive parts and assemblies. You are required to
follow static control precautions when you install,
test, service, or repair this assembly. If you do not
follow ESD control procedures, components can be
damaged. If you are not familiar with static control
procedures, refer to Allen-Bradley publication
8000-4.5.2, Guarding Against Electrostatic Damage
or any other applicable ESD Protection Handbook.
IMPORTANT
To improve the bond between the Ultra3000 and
subpanel, construct your subpanel out of zinc
plated (paint-free) steel.
