Allen-Bradley Ultra3000 User Manual

Publication 2098-IN003E-EN-P — April 2004
Catalog Numbers and Accessories C-5
Motor Feedback Cables
MP-Series Motor Brake Cable
Ultra3000 Interface Cables
Description Catalog Number
H-Series, non-flex, connector at both ends, right angle 2090-UXNFBH-Rxx
H-Series, non-flex, motor connector to flying leads, right angle 2090-UXNFDH-Rxx
H and F-Series, non-flex, connector at both ends, straight 2090-UXNFBHF-Sxx
H and F-Series, non-flex, motor connector to flying leads, straight 2090-XXNFHF-Sxx
H and F-Series, non-flex, connector at both ends, right angle 2090-UXNFBHF-Rxx
H and F-Series, non-flex, connector at both ends, right angle, skewed 2090-UXNFBHF-Kxx
MP-Series (MPL/MPG), non-flex, connector at both ends, straight
2090-UXNFBMP-Sxx
1326AB-Series (M2L/S2L), non-flex, connector at both ends, straight
MP-Series (MPL/MPG), non-flex, motor connector to flying leads, straight
2090-XXNFMP-Sxx
1326AB-Series (M2L/S2L), non-flex, motor connector to flying leads, straight
MP-Series (MPF), non-flex, motor connector to flying leads, straight 2090-XXNFMF-Sxx
N-Series, non-flex, connector at both ends, straight 2090-UXNFBN-Sxx
N-Series, non-flex, motor feedback connector to flying leads, straight 2090-XXNFN-Sxx
N-Series, non-flex, connector at both ends, right angle 2090-UXNFBN-Rxx
N-Series, non-flex, connector at both ends, right angle, skewed 2090-UXNFBN-Kxx
N-Series, non-flex, connector at both ends, right angle, skewed 2090-UXNFBN23-Kxx
N-Series, non-flex, motor connector to flying leads, right angle, skewed 2090-UXNFDN23-Kxx
N-Series, non-flex, motor connector to flying leads, right angle 2090-UXNFDN-Rxx
Y-Series, non-flex, connector at both ends, straight 2090-UXNFBY-Sxx
Y-Series, non-flex, motor feedback connector to flying leads, straight 2090-XXNFY-Sxx
Drive Feedback Cable, non-flex, CN2 connector to flying leads 2090-UXNFM-Sxx
Description Catalog Number
MP-Series motor brake cable, 0.75 mm
2
(18 AWG)
2090-UXNBMP-18Sxx
Description Catalog Number
Serial Interface Cable, 9-pin D-shell, CN3 to personal computer. 2090-UXPC-D09xx
Controller Interface Cable, 44-pin D-shell, CN1 to 1756-M02AE motion
module (two-axis to premolded connector).
2090-U3AE-D44xx
Controller Interface Cable, 44-pin D-shell, CN1 to 1756-M02AE motion
module (single-axis to no connector).
2090-U3CC-D44xx
