Allen-Bradley Ultra3000 - Catalog Numbers and Accessories; Breakout Board Kits; Breakout Boards; Breakout Cables

Publication 2098-IN003E-EN-P — April 2004
C-8 Catalog Numbers and Accessories
Breakout Board Kits
Breakout board kits include the 2090-UxBB-Dxx DIN rail terminal
block, 2090-UxBC-Dxxxx cable, and mounting hardware.
Breakout Boards
1
For specifications, refer to the CN1 Control Interface Breakout Boards Installation Instructions (publication
2090-IN007x-EN-P).
2
This breakout board accepts 1 - 0.14 mm
2
(16 - 26 AWG) wire. For applications that require a 44-pin
drive-mounted breakout board that accepts 4 - 0.5 mm
2
(12 - 22 AWG) wire, contact your local Allen-Bradley
representative.
3
Only for use with the Ultra3000 (2098-DSD-005x-xx, -010x-xx, -020x-xx) drives. Requires an external +24V dc
power supply (refer to Auxiliary 5V Logic Supply on page 2-26). For specifications, refer to the CN1 Control
Interface Breakout Boards with Integral 24V to 5V Auxiliary Power Converter Installation Instructions (publication
2090-IN008x-EN-P).
4
For specifications, refer to the CN2 Motor Feedback Breakout Board Installation Instructions (publication
2090-IN006x-EN-P).
Breakout Cables
Catalog Number Description
2090-UXBK-D15xx 15-pin, high density D-shell for Ultra3000 CN2 interface connector
2090-U3BK-D44xx 44-pin, high density D-shell for Ultra3000 CN1 control interface connector
Catalog Number Description
2090-U3BB-DM12
1
12-pin, drive-mounted breakout board for Ultra3000 CN1 connector recommended
for use with SERCOS interface applications
2090-U3BB2-DM44
1, 2
44-pin, drive-mounted breakout board for Ultra3000 CN1 control interface connector
2090-U3CBB-DM12
3
12-pin, drive-mounted breakout board for Ultra3000 CN1 connector recommended
for use with SERCOS interface applications with 24V to 5V auxiliary power converter
2090-U3CBB-DM44
3
44-pin, drive-mounted breakout board for Ultra3000 CN1 connector with 24V to 5V
auxiliary power converter
2090-U3BB-D44 44-pin, high density D-shell for Ultra3000 CN1 control interface connector
2090-UXBB-DM15
4
15-pin, drive-mounted breakout board for Ultra3000/5000 CN2 interface connector
2090-UXBB-D15 15-pin, high-density D-shell for Ultra3000/5000 CN2 interface connector
2090-UXBB-DM09 9-pin, drive-mounted breakout board for Ultra3000/5000 CN3 serial interface
Catalog Number Description
2090-UXBC-D15xx 15-pin, high-density D-shell for Ultra3000 CN2 interface connector
2090-U3BC-D44xx 44-pin, high density D-shell for Ultra3000 CN1 control interface connector
