Publication 2098-IN003E-EN-P — April 2004
Connecting Your Ultra3000 3-13
Power Wiring
Requirements
Power wiring requirements are given in the tables below. Wire should
be copper with 75° C (167° F) minimum rating, unless otherwise
noted. Phasing of main AC power is arbitrary and earth ground
connection is required for safe and proper operation.
Ultra3000 Power Wiring Requirements
1
The input power may be optionally isolated through a transformer.
Note: Refer to Figure 3.14 for TB1 terminal positions.
IMPORTANT
The National Electrical Code and local electrical
codes take precedence over the values and methods
provided.
Ultra3000 Drives Description
Connects to
Terminals
TB1
Recommended
Wire Size
mm
2
(AWG)
Terminal Block
Torque Values
Nm (lb-in.)
2098-DSD-005x-xx
Input Power
1
100-240V ac
single-phase
1.5 (16)
1.25 (11)
2098-DSD-010x-xx 2.5 (14)
2098-DSD-020x-xx 3 (12)
2098-DSD-030x-xx
Input Power
1
100-240V ac
single-phase
6 (10)
2098-DSD-075x-xx
Input Power
1
100-240V ac
three-phase
2098-DSD-150x-xx 10 (8) 4.0 (35)
2098-DSD-HV030x-xx
Input Power
1
230-480V ac
three-phase
2.5 (14)
1.25 (11)
2098-DSD-HV050x-xx
2098-DSD-HV100x-xx 4 (12)
2098-DSD-HV150x-xx 6 (10)
2098-DSD-HV220x-xx 10 (8)
All Ultra3000 drives
(230V and 460V)
Motor Power
Motor power cable
depends on motor/
drive combination.
L1, L2/N, and
L1, L2/N,
L1 AUX,
and L2/N AUX
L1, L2, L3,
L1 AUX,
and L2/N AUX
L3, L2, L1
L1 AUX,
and L2/N AUX
U, V, W, and
