Publication 2098-IN003E-EN-P — April 2004
C-2 Catalog Numbers and Accessories
Ultra3000 Drives
Use the following table to identify Ultra3000 240V drives with ratings
of 500W, 1 kW, and 2 kW where -xxx equals 005, 010, or 020.
Use the following table to identify Ultra3000 240V drives with ratings
of 3 kW, 7.5 kW, and 15 kW where -xxx equals 030, 075, or 150.
Use the following table to identify Ultra3000 460V drives with ratings
of 3 kW, 5 kW, 10 kW, 15 kW, and 22 kW where -xxx equals 030, 050,
100, 150, or 220.
Software
The Ultra3000-SE drives are configured using RSLogix 5000. Ultra3000,
Ultra3000 with indexing, Ultra3000-DN, and Ultra3000-DN with
indexing drives are configured using Ultraware.
Both are Windows
®
based applications that allow drive configuration
to be done off-line and saved to disk.
Description Catalog Number
Ultra3000 Digital Servo Drive 2098-DSD-xxx
Ultra3000i Digital Servo Drive (with Indexing) 2098-DSD-xxxX
Ultra3000 Digital Servo Drive (with SERCOS) 2098-DSD-xxx-SE
Ultra3000 Digital Servo Drive (with DeviceNet) 2098-DSD-xxx-DN
Ultra3000 Digital Servo Drive (with DeviceNet and Indexing) 2098-DSD-xxxX-DN
Description Catalog Number
Ultra3000 Digital Servo Drive 2098-DSD-xxx
Ultra3000i Digital Servo Drive (with Indexing) 2098-DSD-xxxX
Ultra3000 Digital Servo Drive (with SERCOS) 2098-DSD-xxx-SE
Ultra3000 Digital Servo Drive (with DeviceNet) 2098-DSD-xxx-DN
Ultra3000 Digital Servo Drive (with DeviceNet and Indexing) 2098-DSD-xxxX-DN
Description Catalog Number
Ultra3000 Digital Servo Drive 2098-DSD-HVxxx
Ultra3000i Digital Servo Drive (with Indexing) 2098-DSD-HVxxxX
Ultra3000 Digital Servo Drive (with SERCOS) 2098-DSD-HVxxx-SE
Ultra3000 Digital Servo Drive (with DeviceNet) 2098-DSD-HVxxx-DN
Ultra3000 Digital Servo Drive (with DeviceNet and Indexing) 2098-DSD-HVxxxX-DN
Description Catalog Number
RSLogix 5000 Software (version 11.0 or above) 9324-RLD300ENE
Ultraware Software 2098-UWCPRG
