MU-100A
8. Function Setting
8-5
No Item
Selections,
Setting range
Description
9 Self Hold Validity
Valid(0)
Invalid(1)
Selects pulse input or hold input for the start input.
Valid(0): Pulse input
Input 20ms or more.
Invalid(1): Hold input
When the signal is turned OFF before moving to
Weld-Time, the sequence operation is interrupted.
10 Output Select Time
TACT(0)
50ms(1)
100ms(2)
200ms(3)
300ms(4)
Selects the output state of the GOOD/NG/FINISH
output.
TACT(0): Hold output. Turns OFF at the start of the next
measurement.
50ms(1): Outputs for 50ms.
100ms(2): Outputs for 100ms.
200ms(3): Outputs for 200ms.
300ms(4): Outputs for 300ms.
11 Output Settings
Normal Close(0)
Normal Open(1)
Selects the logical state of the
GOOD/NG/FINISH/WELD START output.
Normal Close(0): Normal close
Normal Open(1): Normal open
12 Level Select Time
TACT(0)
50ms(1)
100ms(2)
200ms(3)
300ms(4)
Selects the output state of the level output.
TACT(0): Hold output. Turns OFF at the start of the next
measurement.
50ms(1): Outputs for 50ms.
100ms(2): Outputs for 100ms.
200ms(3): Outputs for 200ms.
300ms(4): Outputs for 300ms.
13 Level Settings
Normal Close(0)
Normal Open(1)
Selects the logical state of the LEV-DISP/LEV-FORCE
output.
Normal Close(0): Normal close
Normal Open(1): Normal open
14 Head Position
TOP(0)
HOLD(1)
Selects the state of the welding head at the occurrence
of error.
TOP(0): The SV signal is turned OFF.
HOLD(1): The SV signal is kept ON.
15 Finish Validity
Valid(0)
Invalid(1)
Sets whether to output the FINISH signal at STOP or
NG.
Valid(0): Output
Invalid(1): Do not output
16 Disp Voltage Range
±65.535mm(0)
±32.767mm(1)
±16.383mm(2)
±8.191mm(3)
±4.095mm(4)
±2.047mm(5)
±1.023mm(6)
±0.511mm(7)
±0.255mm(8)
Selects the voltage output range of the displacement
sensor.
Saturated when the length is longer than the setting.
±65.535mm (0): Outputs -65.535 to +65.535mm with -10
to +10V voltage.
±32.767mm(1): Outputs -32.767 to +32.767mm with -10
to +10V voltage.
±16.383mm(2): Outputs -16.383 to +16.383mm with -10
to +10V voltage.
±8.191mm(3): Outputs -8.191 to +8.191mm with -10 to
+10V voltage.
±4.095mm(4): Outputs -4.095 to +4.095mm with -10 to
+10V voltage.
±2.047mm(5): Outputs -2.047 to +2.047mm with -10 to
+10V voltage.
±1.023mm(6): Outputs -1.023 to +1.023mm with -10 to
+10V voltage.
±0.511mm(7): Outputs -0.511 to +0.511mm with -10 to
+10V voltage.
±0.255mm(8): Outputs -0.255 to +0.255mm with -10 to
17 Direction Select
-(CCW)(0)
+(CW)(1)
Selects the sign of the displacement sensor.
-(CCW)(0): Decreases in the direction that the rod is
pushed.
+(CW)(1): Increases in the direction that the rod is
To Next Page
