Amada MU-100A - Sample Hold 2 Mode Disp Measure Mode: SH2(3)

MU-100A
12. Timing Chart (2-axis Type)
12-10
(4) Sample Hold 2 Mode “Disp Measure Mode : SH2(3)”
When 0=Setup parameter of the function menu is set as follows:
1 Disp Measure Mode setting: SH2(3)
4ms
3ms
2ms
2ms2ms
20ms min.
(*1)
20ms max.
18ms
LEV-DISP2 set displacement
LEV-DISP1 set displacement
20ms min.
Displacement change 2
Internal
zero reset
GOOD output(*2)
FINISH output(*2)
NG output(*2)
After Weld Work measurement
ST-DISP1 input
Squeeze-Time(setting)
Weld-Time(setting)
(Weld start output)
Welding(power supply)
LEV-DISP11 to 13 output
LEV-DISP21 to 23 output
(*3)
(*3)
After Weld Work
measurement position
Displacement change 1
ST-DISP2 input
*1 Set the time longer than the total weld time of welding machine for Weld-Time.
*2 The output time can be selected with Output Select Time.
*3 The output time can be selected with Level Select Time.
