MU-100A
13. Data Communication
13-1
13. Data Communication
(1) Data Transmission
Item Contents
Mode EIA RS-485-compliant, half-duplex, asynchronous, multi-dropped
connection (up to 31 devices)
EIA RS-232C-compliant, full-duplex
IEEE.802.3-compliant (10BASE-T/100BASE-TX)
Transmission rate
(Baud rate)*
9600, 19200, 38400, 57600 bps
Data bit* 7, 8
Parity* None, odd, even
Stop bit* 1, 2
Data
format
Flow control* None, Xon/Xoff, hardware
FCS (frame checksum)* With, without
(HEX display of simply added value by 1 byte from the first character
to the character before FCS)
Character code ASCII
* Set by “3=Communication” parameter (see 8.(5)).
