Amada MU-100A - Sequence Mode Disp Measure Mode: SQNC(1)

MU-100A
12. Timing Chart (2-axis Type)
12-5
(2) Sequence Mode “Disp Measure Mode : SQNC(1)”
When 0=Setup parameter of the function menu is set as follows:
1 Disp Measure Mode setting: SQNC(1)
2 LS Input Validity setting: Valid(0)
3 Self Hold Validity setting: Valid(0)
18ms
2ms
2ms
1ms3ms
3ms
2ms
2ms
5ms
2ms
1ms
1ms
1ms
Before Weld Work measurement position
Displacement measurement
After Weld Work measurement
Before Weld Work measurement
SV11 to 13,21 to 23 output
LEV-DISP11 to 13 output
LEV-DISP21 to 23 output
(Weld Start output)
LS1 input
ST-DISP1 input
LS2 input
ST-DISP2 input
LEV-DISP1 set displacement
LEV-DISP2 set displacement
Displacement change 2
Displacement change 1
GOOD output(*4)
FINISH output(*4)
NG output(*4)
(*1)
(*6)
(*6)
(*2)
(*5)
(*1)
(*3)
20ms max.
20ms min.
20ms min.
Squeeze-Time(setting)
Weld-Time(setting)
Welding(power supply)
Hold-Time(setting)
After Weld Work
measurement position
*1 When Self Hold Validity is set to Invalid(1), hold the ST-DISP input until the
sequence moves to Weld-Time.
*2 Set the time longer than the total weld time of welding machine for Weld-Time.
