Amada MU-100A - Page 38

MU-100A
8. Function Setting
8-10
b. OUTPUT LED parameter item
Item
Selections
Sym-
bol
Description
LED
display
Initial value
Selections
First axis
Second axis
OL0
Output LED Display0
OUT 0
READY1(0)
READY1(0)
GOOD-DISP1(1)
GOOD-FORCE1(2)
NG1(3)
NG-UP1(4)
NG-LO1(5)
NG-BEFORE1(6)
NG-DISP1(7)
NG-AFTER1(8)
NG-FORCEUP1(9)
NG-FORCELO1(10)
WARNING(11)
WELD START1(12)
FINISH1(13)
LEV-DISP11(14)
LEV-DISP12(15)
LEV-DISP13(16)
LEV-FORCE11(17)
LEV-FORCE12(18)
LEV-FORCE13(19)
SV11(20)
SV12(21)
SV13(22)
OUTPUT11(23)
OUTPUT12(24)
OUTPUT13(25)
OUTPUT14(26)
OUTPUT15(27)
OUTPUT16(28)
READY2(29)
GOOD-DISP2(30)
GOOD-FORCE2(31)
NG2(32)
NG-UP2(33)
NG-LO2(34)
NG-BEFORE2(35)
NG-DISP2(36)
NG-AFTER2(37)
NG-FORCEUP2(38)
NG-FORCELO2(39)
WELD START2(40)
FINISH2(41)
LEV-DISP21(42)
LEV-DISP22(43)
LEV-DISP23(44)
LEV-FORCE21(45)
LEV-FORCE22(46)
LEV-FORCE23(47)
SV21(48)
SV22(49)
SV23(50)
OUTPUT21(51)
OUTPUT22(52)
OUTPUT23(53)
OUTPUT24(54)
OUTPUT25(55)
OUTPUT26(56)
OL1 Output LED Display1 OUT 1 GOOD-DISP1(1)
OL2
Output LED Display2
OUT 2
GOOD-FORCE1(2)
OL3
Output LED Display3
OUT 3
NG1(3)
OL4
Output LED Display4
OUT 4
NG-UP1(4)
OL5
Output LED Display5
OUT 5
NG-LO1(5)
OL6
Output LED Display6
OUT 6
NG-BEFORE1(6)
OL7
Output LED Display7
OUT 7
NG-DISP1(7)
OL8
Output LED Display8
OUT 8
NG-AFTER1(8)
OL9
Output LED Display9
OUT 9
NG-FORCEUP1(9)
OLA
Output LED DisplayA
OUT A
NG-FORCELO1(10)
OLB Output LED DisplayB OUT B WARNING(11)
OLC
Output LED DisplayC
OUT C
WELD START1(12)
OLD
Output LED DisplayD
OUT D
FINISH1(13)
OLE
Output LED DisplayE
OUT E
LEV-DISP11(14)
OLF
Output LED DisplayF
OUT F
LEV-DISP12(15)
