MU-100A
10. Setting of Measurement Mode and Schedule
10-4
Monitoring of the after-welding workpiece thickness
No.6 “After Weld Work LO” (after-welding workpiece thickness lower limit)
No.7 “After Weld Work UP” (after-welding workpiece thickness upper limit)
Monitoring of the workpiece displacement
No.8 “Displacement LO” (workpiece displacement lower limit)
No.9 “Displacement UP” (workpiece displacement upper limit)
6Set the level output according to your use conditions.
Displacement level output
No.14 “Displacement Level1”
No.15 “Displacement Level2”
No.16 “Displacement Level3”
By connecting the external output signals “LEV-DISP11 to 13, 21 to 23” to the
weld stop input of the welding power supply, you can stop the welding after the
displacement value reaches the set value.
c. Measurement
1
Press MONI key to display the normal screen.
2Set the schedule by selecting schedule switching signals “SCH1”, “SCH2”,
“SCH4”, “SCH8”, “SCH16”, “SCH32”, and “SCH64” or via the panel.
3Input “ST-DISP1” or “ST-DISP2” (second axis) to make a measurement.
