MU-100A
10. Setting of Measurement Mode and Schedule
10-11
b. Setting of measurement schedule
1
Press MONI key to display the normal screen.
2Press SCH key to select “SCH Axis”.
3Select the setting object between “Axis1(0)” (first axis) and “Axis2(1)” (second
axis) to set the schedule number.
4Set No.1 “Squeeze-Time”, No.2 “Weld-Time”, and No.3 “Hold-Time” to the time
same as the set time for the welding power supply. When “LS Input Validity”
(force-detecting signal input) is set to “Valid(0)”, “Squeeze-Time” setting is
unnecessary.
5Set the monitoring level according to your use conditions.
Monitoring of the before-welding force
No.10 “Before Weld Force LO” (before-welding force lower limit)
No.11 “Before Weld Force UP” (before-welding force upper limit)
Monitoring of the after-welding force
No.12 “After Weld Force LO” (after-welding force lower limit)
No.13 “After Weld Force UP” (after-welding force upper limit)
6Set the level output according to your use conditions.
Use of Force level output
No.17 “Force Level1”
No.18 “Force Level2”
No.19 “Force Level3”
c. Measurement
1
Press MONI key to display the normal screen.
2Set the schedule by selecting schedule switching signals “SCH1”, “SCH2”,
“SCH4”, “SCH8”, “SCH16”, “SCH32”, and “SCH64” or via the panel.
3Input “ST-FORCE1” or “ST-FORCE2” (second axis) to make a measurement.
