10. Setting of Measurement Mode and Schedule
10-17
3Select the setting object between “Axis1(0)” (first axis) and “Axis2(1)” (second
axis) to set the schedule number.
4Set No.1 “Squeeze-Time”, No.2 “Weld-Time”, and No.3 “Hold-Time” to the time
longer than the set time for the welding power supply. Set the weld time to the
time longer than the set time for the welding power supply.
5Set the monitoring level according to your use conditions.
Monitoring of the before-welding force
No.10 “Before Weld Force LO” (before-welding force lower limit)
No.11 “Before Weld Force UP” (before-welding force upper limit)
Monitoring of the after-welding force
No.12 “After Weld Force LO” (after-welding force lower limit)
No.13 “After Weld Force UP” (after-welding force upper limit)
6Set the level output according to your use conditions.
Use of the force level output
No.17 “Force Level1”
No.18 “Force Level2”
No.19 “Force Level3”
7Set the weld start output force value to your use conditions.
Setting of the weld start output force value
No.21 “Tangential Force”
c. Measurement
1
Press MONI key to display the normal screen.
2Set the schedule by selecting schedule switching signals “SCH1”, “SCH2”,
“SCH4”, “SCH8”, “SCH16”, “SCH32”, and “SCH64” or via the panel.
3Input “ST-FORCE1” or “ST-FORCE2” (second axis) to make a measurement.
